Methanol Injection Pump – 150 PSI 2000cc/min

Features:

• Self-priming high-pressure diaphragm pump
• Air-free design ensures smooth, pulsation-free flow
• Adjustable pressure: 58 – 150 PSI (4–10 bar)
• Flow rate: 2000 cc/min (120 LPH / 31.7 GPH)
• Voltage range: 15V – 35V
• Nominal current: 1A, Max current: 4A
• Constructed from durable HDPE/ABS plastic, rubber, and steel
• 100% methanol compatible – suitable for all alcohol/water mixtures
• No pressure cut-off switch → prevents oscillation and pressure spikes
• Internal bypass provides a steady, constant flow
• Large female ports
• Low RPM motor design (as low as 60 RPM) ensures long lifespan
• Can safely operate dry for up to one hour
• Can accept a 50Hz PWM signal for flow control

📦 Box Contents

1. High-Pressure Diaphragm Pump
2. Product Stickers
3. Installation Manual

Download the WMI Pump.pdf
