The Bosphorus Innovations Stage 4+ PWM Water/Methanol Injection Kit is engineered for high-end professional builds requiring absolute custom control and maximum safety. Controlled via a standalone ECU using 2D or 3D injection maps based on TPS, MAP, or engine load, it features an integrated fast-reacting safety solenoid valve and a generous 5.9L fluid reservoir.
Standalone ECU PWM Control: Program dynamic 2D or 3D injection maps based on Throttle Position Sensor (TPS), Manifold Absolute Pressure (MAP), or overall engine load.
Solenoid Valve Safety Protection: Fast-reacting integrated solenoid locks fluid in place when idle—making it ideal for rear-mounted reservoirs, vacuum zones, or lower nozzle mountings.
Pulsation-Free High-Pressure Pump: Employs an internal bypass architecture instead of a pressure switch for a smooth, constant, and even spray pattern.
Large 5.9L Fluid Reservoir: Includes a generous 5.9-liter plastic tank to guarantee a steady, reliable supply under extreme racing or track conditions.
Bosphorus Innovations Stage 4+ PWM Water/Methanol Injection Kit (Standalone ECU, PWM & Solenoid Controlled)
Designed for professional motorsport applications and advanced engine management setups, the Stage 4+ PWM Water/Methanol Injection Kit puts total fluid delivery control into your standalone ECU. By utilizing pulse-width modulation (PWM) across 2D or 3D maps driven by TPS, MAP, or engine load, the system delivers precise quantities of water-methanol mist to drastically lower manifold air temperatures and exhaust gas temperatures (EGT), protecting pistons from thermal failure while maximizing octane levels.
Advanced Solenoid & Bypass Architecture Unlike standard setups, the Stage 4+ PWM kit includes an integrated fast-reacting solenoid valve mounted directly before the nozzle, providing an injector-style response and eliminating any risk of gravity siphoning. Equipped with a pulsation-free high-pressure diaphragm pump featuring an internal bypass mechanism, the system ensures a steady, oscillation-free stream. All metal components are constructed from corrosion-resistant nickel-plated brass, standard brass, and EPDM-grade plastics certified for 100% methanol durability.
Key Benefits & Features
Combustion Efficiency: Enhances dynamic compression and burn efficiency while reducing harmful emissions (CO, CO2, NOx, and HC).
Complete Professional Package: Includes a 5.9-liter plastic tank, controller with wiring harness, 6 meters of injection tubing, 40-micron stainless steel inline filter, and check valve.
2-Year Warranty: Backed by Bosphorus Innovations’ comprehensive guarantee against manufacturing defects.
Nozzle Selection Guide
100% Water: 10–15% Water-to-Fuel ratio or 0.5–1 cc per HP
50% Water / 50% Methanol: 15–20% Mixture-to-Fuel ratio or 1–1.5 cc per HP
100% Methanol: 20–25% Methanol-to-Fuel ratio or 1.5–2 cc per HP
(Default configuration: 252 ml/min [4 GPH] nozzle and Red Hose if no specific size/color is indicated before ordering).
Technical Specifications
Application: Standalone ECU Controlled Vehicles (PWM Compatible)
Activation Type: Programmable via Standalone ECU (2D/3D Maps: TPS, MAP, or Engine Load) with Solenoid Valve
Tank Capacity: 5.9 Liters / 1.56 Gallons (Plastic Tank)
Hose Length: 20 FT / 6 Meters (¼” OD injection tubing)
Warranty: 2-Year Manufacturer Defect Warranty
Package Contents
High-Pressure Diaphragm Pump with 2 x pump fittings
Injection Nozzle & Nozzle Mounting Bung
Fast-Reacting Solenoid Valve & 40-Micron Stainless Steel Filter with Filter Nut & Check Valve
2 x 1/8” NPT to ¼” compression type fittings
Controller with Wiring Loom
5.9 Liter Plastic Tank with Cap
20 FT / 6 Meters ¼” OD Injection Hose (Red or Blue color options)
Electrical Hardware (2 x Fully Insulated Female Cable Connectors, 2 x Fully Insulated Butt Cable Connectors, Fully Insulated Ground Cable Connector, LED Holder)
Mounting Hardware (5 x Zip Ties, 2 x Tank Screws & Washers, 4 x Pump Screws & Washers)
Branding (3D Sticker & Stickers)
1 x Installation Manual
| Weight | 3 kg |
|---|---|
| Dimensions | 30 × 25 × 12 cm |
| Car Brand | Acura, Alfa Romeo, Aston Martin, Audi, Bentley, BMW, Bugatti, Buick, Cadillac, Caterham, Chery, Chevrolet, Chrysler, Citroën, Cupra, Dacia, Daewoo, Daihatsu, Dodge, DS Automobiles, Eagle, Ferrari, Fiat, Ford, GAZ, Geely, Hennessey, Honda, Hyundai, Ikco, Infiniti, Isuzu, Jaguar, Kia, Koenigsegg, Lada, Lamborghini, Lancia, Lexus, Lincoln, Lotus, Maserati, Mazda, McLaren, Mercedes Benz, Mercury, MG, Mini, Mitsubishi, Morgan, Moskwitsch, Nissan, Oldsmobile, Opel, Other, Pagani, Peugeot, Plymouth, Pontiac, Porsche, Proton, Renault, Rolls-Royce, Rover, Saab, Saturn, Seat, Skoda, Smart, Subaru, Suzuki, Tata, Toyota, Volkswagen, Volvo |
| Engine cc | 1000cc – 1600cc, 1601cc – 2500cc, 2501cc – 4000cc, 4000cc + |
| Fuel Type | Naturally Aspirated Gasoline, Forced Induction Gasoline |
| Hose Color & Type | Nylon Blue, Nylon Red, PTFE-Durable |
| Tank Size | No Tank, Small Size 3 Lt/ 0.8 Gallon, Standard M Tank 5.9 Lt/ 1.58 Gallon, Low Profile 5 Lt/ 1.32 Gallon, L Tank 10 Lt/ 2.64 Gallon, XL Tank 20 Lt/ 5.28 Gallon |
| Mounting Location | Remote Mount – For vehicles with limited space, Standard Mount – For vehicles with ample space, V-Engine Mount – For dual-nozzle hose setups |
